LED Type: 5050 0.5W RGB 3in1 LEDs

LED Count: 576

LED Colors: RGB

LED Segments: 16 (2 x 8)

Strobe Tube LEDs

LED Type: 3535 5W 6800K LEDs

LED Count: 96

LED Colors: Cool-White

LED Segments:8

Strobe Tube LEDs

LED Type: 3535 5W 6800K LEDs

LED Count: 48

LED Colors: Amber

LED Segments:8

Movement

Resolution: 8-16 Bit

Position Feedback: yes

Tilt (Degrees): 185°

Control

Control Modes:7

Display: Illuminated graphic LCD

Protocol: USITT DMX-512, RDM

RDM: Bidirectional communication

Wireless DMX: 2.4 GHz W-DMX＆#8482; (optional)

Cooling: Temperature controlled, overheating protection

Effects

Dimmer: 0-100% electronic Shutter:

electronic, max. 20 Hz Internal

Effects: LED Macro Effects

Connectors

Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out

Power Input: Seetronic powerCON TRUE1 In/Out

Operating Condtions

Mains voltage: 100-240V AC / 50-60Hz

Power: 1200W

Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F Operating

Position: any

Mounting Options

Standing: Rubber feet

Hanging: Omega-Bracket

Safety wire attachment: foldout eyelets Shipping

Single fixture: cardboard (inner and outer cartons)

Tourpack: 4-way Flight Case

Housing Colors

Standard colors: black

Dimensions & Weight

Dimensions:502 mmx137mm x326 mm

Weight

N.W: 11.2 kg G.W: 13.5 kg
